FALCON LOCK W 101 DAN 613 PASSAGE SET
FALCON LOCK W 101 DAN 613 PASSAGE SET
Falcon W101S - Grade 2 Passage Lever Set - ANSI F75
Latch bolt by levers at all times.
Lever: D - Dane
Finish{ Oil rubbed bronze 613
Door Thickness: 1-3/8" to to 1-3/4" standard.
Backset: 2-3/4" standard
Handing: Locks are non-handed.
Trim: Heavy wrought brass or bronze, installed over steel rose inserts which are through-bolted through door. Levers are pressure-cast zinc (solid levers-no-inserts) finished to match mating parts.
Latches: 1/2" bolt projection made of stainless steel and UL listed for 3-hour door assemblies. Latches have self-adjusting fronts to accommodate beveled or flat doors. 2-3/8backset with 2-1/4" x 1latch faces or 2-3/4" backset with 2-1/4" x 1-1/8" latch faces.
Strike: 4-7/8" x 1-1/4" ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard. Consult
ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 2.
UL: 3 hour A label
loca GLF/PNK
